Overview
Spearfish C Deore Di2 is an endurance XC MTB built to cover as much ground as possible, no matter how challenging. Its light, responsive carbon fiber frame meshes perfectly with the efficiency of our Split Pivot suspension design for finely balanced pedaling and braking performance. 120mm of front and rear travel soaks up all the technical terrain you’ll find on your local loop, bikepacking race, and beyond. The geometry allows efficient pedaling for chasing FKTs, and grants a boost of confidence on terrain that wants to throw you off your game.
Spearfish makes it easy to pack for big days out, with space for up to three bottles (sizes MD–XL), and cargo and accessory mounts that can also accommodate a sizeable direct-mount frame bag if that’s your jam. Shimano’s Deore Di2 groupset offers effortless, speedy electronic shifting so you can preserve every ounce of mental and physical energy as you push your limits.
Features
Carbon fiber frame, seatstays, and chainstays with carbon fiber links for weight, stiffness, and durability
Split Pivot suspension design features 120mm of travel that’s responsive when putting down power, fully active under braking, and supportive throughout the middle and end of its stroke, paired with a 120mm suspension fork
Split Pivot + design philosophy lets riders adjust rear travel from 100–120mm; compatible with 100–130mm forks
Endurance XC geometry with 66.3-degree head tube angle and 77.3-degree seat tube angle
Rear flip chip adjusts the head tube angle and bottom bracket height to accommodate varying terrain and personal preference
Sizes XS–SM fit two full-size bottles, plus accessory mount; sizes MD–XL fit three full-size bottles
Top tube mounts for use with EXP-R Series Trillium Top Tube Bag or K-Edge computer mounts
Tool and tube mount location
Clearance for up to 29 x 2.4″ tires
Molded frame protection
Specs
| Frame measurements (mm) | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| A. BB Drop | 31 / 35.4 | 31 / 35.5 | 31 / 35.5 | 31 / 35.6 | 31 / 35.6 |
| B. Chainstay Length | 430 / 431.2 | 430 / 431.2 | 430 / 431.2 | 430 / 431.2 | 430 / 431.2 |
| C. Fork Length – Axle to Crown | 530 | 530 | 530 | 530 | 530 |
| D. Fork Offset | 44 | 44 | 44 | 44 | 44 |
| E. Head Tube Angle (deg) | 66.3 / 66.0 | 66.3 / 66.0 | 66.3 / 66.0 | 66.3 / 66.0 | 66.3 / 66.0 |
| F. Headtube Length | 95 | 105 | 115 | 125 | 130 |
| G. Reach | 435 / 431.4 | 450 / 446.5 | 470 / 466.5 | 490 / 486.4 | 510 / 506.5 |
| H. Seat Tube Angle (deg) | 77.3 / 77.0 | 777.3 / 77.0 | 77.3 / 77.0 | 77.3 / 77.0 | 77.3 / 77.0 |
| I. Seat Tube Length – Center to Top | 380 | 405 | 430 | 455 | 480 |
| J. Stack | 589.3 / 591.9 | 598.4 / 601.1 | 607.6 / 610.3 | 616.7 / 619.6 | 625.9 / 628.8 |
| K. Standover | 719.2 / 716.3 | 719.2 / 716.3 | 719.2 / 716.3 | 719.2 / 716.3 | 719.2 / 716.3 |
| L. Top Tube Length (Effective) | 567.8 / 568.6 | 584.9 / 585.7 | 606.9 / 607.7 | 629.0 / 629.8 | 651.1 / 651.9 |
| M. Wheelbase | 1157.0 / 1157.7 | 1176.1 / 1176.7 | 1200.0 / 1200.7 | 1224.1 / 1224.7 | 1248.1 / 1248.7 |
| Component measurements (mm) | |||||
| Crank Arm Length | 165 | 165 | 165 | 165 | 165 |
| Handlebar Width | 760 | 760 | 780 | 780 | 780 |
| Handlebar Rise | 20 | 20 | 20 | 20 | 20 |
| Stem Length | 50 | 50 | 50 | 50 | 50 |
* All dimensions are preliminary and subject to change. Note: Where two measurements are listed, the first number is with Flip Chip in default High position; the second number is with Flip Chip in Low position.
Frameset
Frame: Spearfish Carbon
Fork: Fox 34 SL Performance Elite GRIP X, 44mm offset, 120mm travel
Rear Shock: Fox Float SL Performance Elite, LV, 190 x 45mm
Color: Amber
Drivetrain
Crankset: Shimano Deore M6120-1, 32t
Front Derailleur: N/A
Rear Derailleur: Shimano Deore M6260 SGS Di2
Cassette: Shimano Deore M6100-12, Hyperglide+, 10–51t, 12-speed
Chain: Shimano Deore M6100
Components
Grips / Bar Tape: WTB Wavelength Lock-On
Handlebar: Race Face Aeffect 35.0mm
Stem: Salsa Guide 35.0
Headset: FSA Orbit 1.5E ZS NO.57E
Shifter: Shimano Deore M6250-R
Brakes & Rotors: Shimano Deore M6100 levers, Shimano Deore M6120 4-piston calipers, Shimano RT64 rotors (Center Lock, 180mm front and rear)
Saddle: WTB Silverado Steel Fusion Form, medium
Seatpost: TranzX YSI08 RAD+ adjustable-travel dropper, Shimano MT500 lever
Dropper Travel: XS: 125mm / SM–MD: 150mm / LG: 170mm / XL: 200mm
Wheels
Front Wheel: Shimano TC500 15 x 110mm hub, WTB KOM Team i30 TCS, 28h, 29″ rim
Rear Wheel: Shimano TC500 12 x 148mm hub, WTB KOM Team i30 TCS, 28h, 29″ rim
Tires: Front: Teravail Drawpoint 29 x 2.4″, 120TPI Light Trail casing, tan wall / Rear: Teravail Camrock 29 x 2.4″, 120TPI Light Trail casing, tan wall
Tubeless Accessories: WTB TCS sealant and valves included
Other
Pedals: Not included
Specifications are subject to change without notice.
Warranty
Register your purchase at Salsa’s Warranty Registration.
LIMITED WARRANTY
Salsa Cycles ( “Salsa ” ) makes the following limited Warranty:
All Salsa products are warranted against manufacturing defects in materials and workmanship from the date of retail purchase of the product, subject to the limitations detailed below. Every Salsa frame, component, and apparel has a useful product life cycle. The length of that useful product life cycle will vary depending on the construction and the materials of the product, maintenance and care the product receives, and the amount and type of use the product is subjected to over its life. Your bike has an intended level of use as defined by the ASTM Riding Condition Classification Chart. Failure to adhere to the use cases identified in this chart will void your warranty. Save your dated receipt for proof of purchase.
NOTE:
All warranty periods below apply to the original owner only
ONE YEAR WARRANTY
All apparel
All frame bags
Salsa Cycles does not guarantee the compatibility of original components with a warranty replacement frame. Salsa Cycles is not responsible for parts or labor required to remove and/or refit and re-adjust the product within the bicycle assembly, including wheel rebuilds.
Salsa Cycles cannot guarantee a color match to the original frame, component, or apparel in the event of a replacement.
This warranty applies to 2014 and newer model bicycles and covers only Salsa Cycles branded product. Any other original part or component shall be covered by the stated warranty of the original manufacturer. Any products not specifically included above are hereby excluded.
TWO YEAR WARRANTY
Aluminum chainstays of suspension frames
Aluminum seatstays of suspension frames
Carbon seatstays of suspension frames
All other suspension frame parts (excludes hanger, pivot hardware, bearings)
THREE YEAR WARRANTY
Aluminum frames
Aluminum front triangles of suspension frames
All Salsa forks
All Salsa components
FIVE YEAR WARRANTY
Steel frames
Titanium frames
Carbon frames
Carbon front triangle of suspension frames
THE WARRANTY DOES NOT COVER THE FOLLOWING
Damage due to improper assembly or follow-up maintenance or lack of skill, competence or experience of the user or assemble
Bicycles that were not assembled or serviced by an authorized Salsa Cycles dealer
Products that have been modified, neglected, used in competition, or for commercial purposes such as rental, courier, police, security, etc, misused or abused, involved in accidents or anything other than normal use
Installation of components, parts, or accessories not originally intended for use with or compatible with Salsa frames and components
Salsa Cycles bicycles, frames, components or softgoods purchased from an unauthorized dealer
Salsa Cycles bicycles, frames, components or softgoods purchased from third-party internet sites, including auction websites, and regional trading websites (examples: Amazon, eBay, and Craigslist) are not covered under this warranty, even if you have a receipt
Sandblasting, sanding, grinding, wire brushing, filing, welding, brazing, drilled holes, anodizing, refinishing, powder coating, or chrome plating the bicycle, frame, or component will void the warranty
Internal rust perforation on all steel frames
Wear, scratches, chips and cracks to paint, finish, or coating on all Salsa frames and components
Bent or broken derailleur hangers or Alternator plates
Labor required to remove and/or refit and re-adjust the product within the bicycle assembly, including wheel rebuilds
Damage to carbon fiber caused by any carbon assembly paste
Normal wear and tear
LEGAL DISCLAIMER
This limited warranty is expressly limited to the repair or replacement of a defective product, at the option of Salsa Cycles, and is the sole remedy of the warranty. This limited warranty applies only to the original purchaser of the Salsa Cycles product and is not transferable. This warranty applies only to Salsa Cycles products purchased through an authorized dealer or distributor. In no event shall Salsa Cycles be liable for any loss, inconvenience or damage, whether direct, incidental, consequential, or otherwise resulting from breach of any express or implied warranty or condition of merchantability, fitness for a particular purpose, or otherwise with respect to our products except as set forth herein. This warranty gives the consumer specific legal rights, and those rights and other rights may vary from place to place. This warranty does not affect your statutory rights.
TO THE EXTENT NOT PROHIBITED BY LAW, THESE WARRANTIES ARE EXCLUSIVE AND THERE ARE NO OTHER EXPRESS OR IMPLIED WARRANTIES OR CONDITIONS INCLUDING WARRANTIES OR CONDITIONS OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE.
For 2013 and older model bicycles and products, please consult your Owner’s Manual, Salsa Cycles product instructions, or contact Salsa Cycles or your authorized Salsa dealer for the applicable warranty information.
