Overview
Faster, farther, more efficient: that’s the Spearfish ethos. Our endurance XC mountain bike is built with our all-new Deluxe carbon construction option that’s more than 250 grams lighter than our standard carbon offering. This stiff, lightweight carbon frame translates more of your pedal power into propulsion and rewards you with responsive handling. 120mm of Split Pivot rear suspension travel provides supreme pedaling efficiency and active traction throughout its travel. A 120mm Fox 34 SL Performance Elite GRIP X fork delivers 120mm of front suspension travel to keep you in control over rugged tracks.
Convenient cargo mounts let you adapt your loadout for casual trail rides with friends or can’t-stop FKT attempts. Carry two bottles (or up to three on MD–XL frames), your repair kit, and accessories like our EXP-R Series Trillium Top Tube Bag or a K-Edge computer mount — all on your frame. The SRAM GX Transmission groupset combines the precision and speed of electronic shifting with the durability of SRAM’s Full Mount derailleur design for a system that’s more hurry, less worry.
Spearfish C DLX GX Transmission is the perfect endurance and XC mountain bike for chasing your next monumental Adventure by Bike.
Features
Deluxe carbon fiber frame — Salsa’s most premium carbon construction ever, saving 255 grams over the standard carbon frame with no penalty in durability, stiffness, or ride quality
Split Pivot suspension design features 120mm of travel that’s responsive when putting down power, fully active under braking, and supportive throughout the middle and end of its stroke
Split Pivot + design philosophy lets riders adjust rear travel from 100–120mm; compatible with 100–130mm forks
Endurance XC geometry with 66.3-degree head tube angle and 77.3-degree seat tube angle
Rear flip chip adjusts the head tube angle and bottom bracket height to accommodate varying terrain and personal preference
Sizes XS–SM fit two full-size bottles, plus accessory mount; sizes MD–XL fit three full-size bottles
Top tube mounts for use with EXP-R Series Trillium Top Tube Bag or K-Edge computer mounts
Tool and tube mount location
Clearance for up to 29 x 2.4″ tires
Molded frame protection
Specs
| Frame measurements (mm) | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| A. BB Drop | 31 / 35.4 | 31 / 35.5 | 31 / 35.5 | 31 / 35.6 | 31 / 35.6 |
| B. Chainstay Length | 430 / 431.2 | 430 / 431.2 | 430 / 431.2 | 430 / 431.2 | 430 / 431.2 |
| C. Fork Length – Axle to Crown | 530 | 530 | 530 | 530 | 530 |
| D. Fork Offset | 44 | 44 | 44 | 44 | 44 |
| E. Head Tube Angle (deg) | 66.3 / 66.0 | 66.3 / 66.0 | 66.3 / 66.0 | 66.3 / 66.0 | 66.3 / 66.0 |
| F. Headtube Length | 95 | 105 | 115 | 125 | 130 |
| G. Reach | 435 / 431.4 | 450 / 446.5 | 470 / 466.5 | 490 / 486.4 | 510 / 506.5 |
| H. Seat Tube Angle (deg) | 77.3 / 77.0 | 777.3 / 77.0 | 77.3 / 77.0 | 77.3 / 77.0 | 77.3 / 77.0 |
| I. Seat Tube Length – Center to Top | 380 | 405 | 430 | 455 | 480 |
| J. Stack | 589.3 / 591.9 | 598.4 / 601.1 | 607.6 / 610.3 | 616.7 / 619.6 | 625.9 / 628.8 |
| K. Standover | 719.2 / 716.3 | 719.2 / 716.3 | 719.2 / 716.3 | 719.2 / 716.3 | 719.2 / 716.3 |
| L. Top Tube Length (Effective) | 567.8 / 568.6 | 584.9 / 585.7 | 606.9 / 607.7 | 629.0 / 629.8 | 651.1 / 651.9 |
| M. Wheelbase | 1157.0 / 1157.7 | 1176.1 / 1176.7 | 1200.0 / 1200.7 | 1224.1 / 1224.7 | 1248.1 / 1248.7 |
| Component measurements (mm) | |||||
| Crank Arm Length | 165 | 165 | 165 | 170 | 170 |
| Handlebar Width | 760 | 760 | 800 | 800 | 800 |
| Handlebar Rise | 10 | 10 | 20 | 20 | 20 |
| Stem Length | 50 | 50 | 50 | 50 | 50 |
* All dimensions are preliminary and subject to change. Note: Where two measurements are listed, the first number is with Flip Chip in default High position; the second number is with Flip Chip in Low position.
Frameset
-
Frame: Spearfish Carbon Deluxe
-
Fork: Fox 34 SL Performance Elite, GRIP X, 120 mm
-
Rear Shock: Fox Float SL LV Performance Elite
-
Color: Citrus Green
Drivetrain
-
Crankset: SRAM GX Eagle Transmission, 32t
-
MRP 1x SL TR2 Guide (28–34t compatible)
-
-
Front Derailleur: N/A
-
Rear Derailleur: SRAM GX Eagle Transmission
-
Cassette: SRAM GX Eagle XS-1275, 10–52t, 12-speed
-
Chain: SRAM GX Eagle Transmission Flattop
Components
-
Grips: WTB Wavelength Lock-On
-
Handlebar: Race Face Turbine
-
Stem: Salsa Guide Trail 35.0, 50 mm
-
Headset: FSA Orbit 1.5E ZS NO.57E
-
Shifter: SRAM AXS Pod Rocker (MatchMaker X clamp)
-
Brakes: SRAM Motive Bronze Stealth, 4-piston
-
Rotors: SRAM CenterLine 2.0, 180 mm (front & rear, 6-bolt)
-
Saddle: WTB Silverado, Medium, Cromoly rails, DNAx
-
Seatpost: TranzX YSI08 RAD+ Dropper
-
XS: 125 mm travel
-
SM–MD: 150 mm travel
-
LG–XL: 170 mm travel
-
Wheels & Tires
-
Front Wheel: WTB Frequency 15×110 mm hub, WTB KOM Light i30 TCS, 28h rim
-
Rear Wheel: WTB Frequency 12×148 mm hub, WTB KOM Light i30 TCS, 28h rim
-
Tires: Teravail Camrock 29×2.4″, Light Trail casing, tan sidewalls (front & rear)
-
Tubeless: WTB TCS sealant included
***Specifications are subject to change without notice.***
Warranty
WARRANTY REGISTRATIONS
Register your purchase at Salsa’s Warranty Registration.
LIMITED WARRANTY
Salsa Cycles ( “Salsa ” ) makes the following limited Warranty:
All Salsa products are warranted against manufacturing defects in materials and workmanship from the date of retail purchase of the product, subject to the limitations detailed below. Every Salsa frame, component, and apparel has a useful product life cycle. The length of that useful product life cycle will vary depending on the construction and the materials of the product, maintenance and care the product receives, and the amount and type of use the product is subjected to over its life. Your bike has an intended level of use as defined by the ASTM Riding Condition Classification Chart. Failure to adhere to the use cases identified in this chart will void your warranty. Save your dated receipt for proof of purchase.
NOTE:
All warranty periods below apply to the original owner only
ONE YEAR WARRANTY
All apparel
All frame bags
Salsa Cycles does not guarantee the compatibility of original components with a warranty replacement frame. Salsa Cycles is not responsible for parts or labor required to remove and/or refit and re-adjust the product within the bicycle assembly, including wheel rebuilds.
Salsa Cycles cannot guarantee a color match to the original frame, component, or apparel in the event of a replacement.
This warranty applies to 2014 and newer model bicycles and covers only Salsa Cycles branded product. Any other original part or component shall be covered by the stated warranty of the original manufacturer. Any products not specifically included above are hereby excluded.
TWO YEAR WARRANTY
Aluminum chainstays of suspension frames
Aluminum seatstays of suspension frames
Carbon seatstays of suspension frames
All other suspension frame parts (excludes hanger, pivot hardware, bearings)
THREE YEAR WARRANTY
Aluminum frames
Aluminum front triangles of suspension frames
All Salsa forks
All Salsa components
FIVE YEAR WARRANTY
Steel frames
Titanium frames
Carbon frames
Carbon front triangle of suspension frames
THE WARRANTY DOES NOT COVER THE FOLLOWING
Damage due to improper assembly or follow-up maintenance or lack of skill, competence or experience of the user or assemble
Bicycles that were not assembled or serviced by an authorized Salsa Cycles dealer
Products that have been modified, neglected, used in competition, or for commercial purposes such as rental, courier, police, security, etc, misused or abused, involved in accidents or anything other than normal use
Installation of components, parts, or accessories not originally intended for use with or compatible with Salsa frames and components
Salsa Cycles bicycles, frames, components or softgoods purchased from an unauthorized dealer
Salsa Cycles bicycles, frames, components or softgoods purchased from third-party internet sites, including auction websites, and regional trading websites (examples: Amazon, eBay, and Craigslist) are not covered under this warranty, even if you have a receipt
Sandblasting, sanding, grinding, wire brushing, filing, welding, brazing, drilled holes, anodizing, refinishing, powder coating, or chrome plating the bicycle, frame, or component will void the warranty
Internal rust perforation on all steel frames
Wear, scratches, chips and cracks to paint, finish, or coating on all Salsa frames and components
Bent or broken derailleur hangers or Alternator plates
Labor required to remove and/or refit and re-adjust the product within the bicycle assembly, including wheel rebuilds
Damage to carbon fiber caused by any carbon assembly paste
Normal wear and tear
LEGAL DISCLAIMER
This limited warranty is expressly limited to the repair or replacement of a defective product, at the option of Salsa Cycles, and is the sole remedy of the warranty. This limited warranty applies only to the original purchaser of the Salsa Cycles product and is not transferable. This warranty applies only to Salsa Cycles products purchased through an authorized dealer or distributor. In no event shall Salsa Cycles be liable for any loss, inconvenience or damage, whether direct, incidental, consequential, or otherwise resulting from breach of any express or implied warranty or condition of merchantability, fitness for a particular purpose, or otherwise with respect to our products except as set forth herein. This warranty gives the consumer specific legal rights, and those rights and other rights may vary from place to place. This warranty does not affect your statutory rights.
TO THE EXTENT NOT PROHIBITED BY LAW, THESE WARRANTIES ARE EXCLUSIVE AND THERE ARE NO OTHER EXPRESS OR IMPLIED WARRANTIES OR CONDITIONS INCLUDING WARRANTIES OR CONDITIONS OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE.
For 2013 and older model bicycles and products, please consult your Owner’s Manual, Salsa Cycles product instructions, or contact Salsa Cycles or your authorized Salsa dealer for the applicable warranty information.
