Overview
Our inspiring overview is coming soon. For now, here is what Bombtrack has to say:
The most accessibly-priced adventure-touring bike we produce, the Beyond 1 serves as the perfect first bike for fledgling adventurists. With tyres as wide as a mountain bike accompanied by a 28 / 40T chainset, this bike will be able to reach wherever you’ve plotted on the map. Leverage-boosting bars provide added control, and an eye-watering selection of mounting points mean you won’t need to leave anything at home. Its simplicity makes it easy to service, too.
Features
- Size XS and S will come with 650B wheels
- Double butted crmo steel frame
- Internal light cable routing
- Rack, bag and fender mounts
- Tubeless ready
Specs
- Frame: 4130 double butted crmo, TA, rack / fender mounts, internal light cable routing, 73 mm BSA BB shell
- Fork: 4130 crmo, double butted blades, TA, 1.1/2” – 1.1/8”, fender / rack / triple cage mounts, internal hub dynamo cable routing
- Handlebar: BOMBTRACK BEYOND travel bar, 31.8 mm, 30° flare
- Grips: BOMBTRACK COMMAND bar tape
- Stem: BOMBTRACK WANDER forged aluminium stem, +17°
- Headset: Sealed external aheadset, 1.1/2” – 1.1/8”
- Levers: SRAM Apex double tap mechanic
- Shifter: SRAM Apex double tap 2 x 10
- Brakes: TRP SPYRE C mechanic disc brakes with 180 mm F / 160 mm R rotors
- Crankset: BOMBTRACK AMES forged aluminium crank, 24 mm spindle
- BB: BSA sealed BB, external cups
- Pedals: –
- Chain: KMC X10 chain, 1/2” x 11/128”, 114L
- Chainring: Aluminium / Steel, 40 / 28 T
- Cassette: SRAM PG-1020 10-speed, 11 – 36 T
- Front derailleur: Microshift FD-M612-B
- Rear derailleur: SRAM GX, long cage
- Rear derailleur: SRAM GX, long cage
- Front hub: BOMBTRACK GRAD sealed, 6-bolt disc hub, 15 x 100 mm thru-axle
- Rear hub: BOMBTRACK ARC sealed hub,11-speed, 6-bolt disc, 12 x 142 mm thru-axle
- Front rim: WTB ST i23 double wall, TCS 2.0, 32h
- Rear rim: WTB ST i23 double wall, TCS 2.0, 32h
- Saddle: BOMBTRACK ORIGIN saddle
- Seat post: BOMBTRACK BEECH 27.2 mm x 400 mm
- Seat clamp: BOMBTRACK ORIGIN 29.8 mm
- Tire clearance: XS – S 27.5″ x 2.1″ / M – XL 29″ x 2.1″
- Front tire: WTB RANGER TCS LIGHT / FAST ROLLING XS – S 27.5” x 2.0” / M – XL 29” x 2.0”, tubeless ready
- Rear tire: WTB RANGER TCS LIGHT / FAST ROLLING XS – S 27.5” x 2.0” / M – XL 29” x 2.0”, tubeless ready
- Weight: 12.9 kg (size M)
- Weight frameset: 2540 g frame (size M, incl. TA, bolts, seatclamp, hanger); 1500 g fork (300 mm steerer, incl. TA)
- Maximum rider weight: 140 kg incl. luggage
Note: To help choose the correct size, view the Bombtrack Sizing Recommendations
Warranty
All Bombtrack bicycles are backed by warranty against defects in material and manufacturing.
Please see Bombtrack’s Warranty Page to review their limitations.
