Overview
The Unit X Cromoly frame, rigid fork, and well-geared 12-speed drivetrain keep it simple, durable, and ready for singletrack, forest roads, loaded adventures, or whatever strange detour pulls you out of the main plot. Modular dropouts even let you run it as a single speed when things need to get a little more surreal. It’s hard to categorize, oddly practical, and much easier to understand once you’ve experienced it. The Unit X isn’t for everyone, and that’s probably why everyone who gets it won’t shut up about it.
Features
Reynolds 520 Steel Frame: The butted cromoly frame offers durability, comfort, and a lively ride feel.
Shimano Deore 1×12 Drivetrain: The 32t chainring and wide-range 10–51t cassette provide simple shifting with low climbing gears.
29 × 2.6-Inch Tires: High-volume Maxxis Rekon tires add traction, cushioning, and control on loose or rough trails.
Tubeless-Compatible Rims and Tires: WTB TCS rims and Maxxis TR tires can be set up tubeless with the required tape, valves, and sealant.
Boost Hub Spacing: The 110mm front and 148mm rear hubs support stronger wheels and generous tire clearance.
Hydraulic Disc Brakes: Shimano MT410 brakes provide consistent stopping power with a larger 180mm front rotor.
Rigid Plus Fork: The Kona Plus Fork keeps the front end simple while supporting the wide front tire.
Specs
| Size | S | M | L | XL | |
| 1 | ST Length | 370 | 420 | 470 | 530 |
| 2 | TT Length | 582 | 610 | 637 | 675 |
| 3 | Reach | 425 | 450 | 475 | 510 |
| 4 | Stack | 588 | 597 | 606 | 615 |
| 5 | Standover | 695 | 731 | 768 | 810 |
| 6 | HT Angle | 68.0 | 68.0 | 68.0 | 68.0 |
| 7 | HT Length | 110 | 120 | 130 | 140 |
| 8 | ST Angle | 75.0 | 75.0 | 75.0 | 75.0 |
| 9 | CS Length | 430 | 430 | 430 | 430 |
| 10 | BB Drop | 65 | 65 | 65 | 65 |
| 11 | BB Height | 310 | 310 | 310 | 310 |
| 12 | Wheelbase | 1115 | 1144 | 1173 | 1211 |
| 13 | Front Center | 693 | 722 | 750 | 789 |
| 14 | Fork Length | 470 | 470 | 470 | 470 |
| 15 | Fork Offset | 50 | 50 | 50 | 50 |
Frameset
Frame: Reynolds 520 Butted Cromoly
Fork: Kona Plus Fork, 110mm spacing
Sizes: S, M, L, XL
Color: Gloss Metallic Dark Faux Raw with Tonal Charcoal decals
Drivetrain
Crankset: Shimano Deore, 32t, 12-speed
Crank Length: 170mm (S), 175mm (M–XL)
Bottom Bracket: Shimano BSA, 73mm
Rear Derailleur: Shimano Deore
Shifter: Shimano Deore, 12-speed
Cassette: Shimano Deore, 10–51t, 12-speed
Chain: Shimano Deore, 12-speed
Front Derailleur: None
Pedals: Kona JS2
Brakes
Brake Levers: Shimano MT410 hydraulic
Brake Calipers: Shimano MT410 hydraulic
Front Rotor: Shimano RT10, 180mm
Rear Rotor: Shimano RT10, 160mm
Components
Headset: FSA No. 10, ZS44/ZS44
Handlebar: Kona XC/BC Riser, 750mm wide
Stem: Kona XC/BC
Stem Length: 50mm (S–M), 60mm (M–L), as supplied
Seatpost: Kona Thumb with offset, 31.6mm
Seatpost Length: 350mm (S–M), 375mm (L–XL)
Seat Clamp: Kona Clamp, 34.9mm
Grips: Kona Key Grip lock-on
Saddle: WTB Volt Medium
Wheels and Tires
Front Hub: Formula, 15 × 110mm
Rear Hub: Formula, 12 × 148mm, Micro Spline
Front Rim: WTB ST i30 2.0 TCS
Rear Rim: WTB ST i30 2.0 TCS
Spokes: 2.0mm stainless steel, black
Front Tire: Maxxis Rekon TR, 29 × 2.6 inches
Rear Tire: Maxxis Rekon TR, 29 × 2.6 inches
Warranty
Kona’s bicycles fall between a 1 and 2 year warranty. Please see Kona’s extensive warranty details to review their limitations.
