Kona Honzo ESD

Overview

The Radical Slacker – we initially built the Honzo ESD as a test case for the long and low geometry we were developing for the Process X. Most hardtails tend to be somewhat conservative in their geometry. The Honzo ESD is anything but that. Its cromoly steel frame features a head and seat angle that would be right at home on a modern long travel full suspension bike. Wrapped around a 150mm fork, 4-piston brakes front and rear, shod with meaty Maxxis rubber and featuring a headtube badge may or may not open up the gates to The Underworld, the Honzo ESD is an exercise in barely restrained aggression.

Features

Innovate Cromoly steel frame

Internal headset

Tapered head tube

Tubeless compatible rims

Boost standard

Specs

Frameset

Frame: Kona Cromoly Butted
Fork: Marzocchi Bomber Z1 Grip Damper, 150mm, Tapered, 110mm Spacing

Drivetrain

Front Derailleur: n/a
Rear Derailleur: SRAM GX Eagle
Cassette: SRAM GX 10-52t 12spd
Crankset: SRAM GX Eagle 30t X-Sync Eagle
Shifter: SRAM GX Eagle
Chain: SRAM NX Eagle
Chainguide: MRP

Brakes

Brakes: SRAM DB8
Rotors: F-SRAM Centerline 200mm, R-SRAM Centerline 200mm
Brake Levers: SRAM DB8

Cockpit

Headset: FSA Orbit 1.5 E ZS
Handlebar: Race Face Aeffect R 35
Stem: Race Face Aeffect R 35
Grips: Kona Key Grip
Seatpost: TranzX Dropper +RAD Internal 31.6mm
Seat Clamp: Kona Clamp
Saddle: WTB Volt

Wheels

Front Hub: Race Face AR 30 110x15mm
Rear Hub: Race Face AR 30 148x12mm
Spokes: Stainless Black 14g
Rims: Race Face AR 30
Front Tire: Maxxis Assegai EXO TR 3C 29×2.5″ WT
Rear Tire: Maxxis Minion DHR II EXO TR 3C 29×2.4″ WT

SIZE	S	M	L	XL
1	STL	380	380	420	450
2	TTL	578	605	633	670
3	REACH	440	465	490	525
4	STACK	625	634	643	652
5	SO	712	710	709	706
6	HTA	63.0	63.0	63.0	63.0
7	HTL	90	100	110	120
8	STA	77.5	77.5	77.5	77.5
9	CSL	417	417	417	417
10	BBD	62.5	62.5	62.5	62.5
11	BBH	312.5	312.5	312.5	312.5
12	WB	1186	1216	1245	1285
13	FC	776	806	835	875
14	FL	560	560	560	560
15	OF	42	42	42	42

Warranty

Kona’s bicycles fall between a 1 and 2 year warranty. Please see Kona’s extensive warranty details to review their limitations.

01/10/2026

Gustavo S.

Good with issues.

I’ll be honest I don’t have much time logged on the bike. I don’t live close to any parks, so I basically gave it a basic test drive once I installed the pedals. The purchasing of the bike and the shipping was very seamless, however the issue I have was that the bike came with several scuff marks and one paint chip on the frame. The box arrived intact with no damage, so I am left to assume that it was caused by the assembler that assembled my bike at Campfire. Besides the scuff marks and paint chip on the frame, the bike looks awesome and seems to work great! I did reach out to Campfire and they did give me a $100 credit for the cosmetic issues. So overall I am satisfied with the product.

Kona Honzo ESD - Large
