BOB Trailer Quick Release

$27.00$35.00

Clear
SKU: BOBTRQU Category: Tag:

The BOB Quick Release enables you to use a BOB trailer with virtually any bike with a rear quick release. Get an extra BOB quick release to have a second bicycle setup and ready to hook up your BOB. And for long bike tours, we recommend purchasing an extra QR in case it is lost or damaged. The 125mm to 140mm size will fit all standard road and mountain bike sizes. The 145mm size fits the majority of tandem bicycles. The 160mm size fits the Santana tandem bicycles. This 160mm BOB QR is designed to work with the Santana Fork. (Please Note: Quick release sizes do not indicate the length of the skewer, rather they indicate the width of the bicycle’s rear hub that the quick release is being mounted to. This is a measurement of the outside edge to outside edge of the hubs outer nuts that interface with the bicycle frame’s dropouts.)



Overview

BOB QRs Rule The World.

The BOB Quick Release enables you to use a BOB trailer with virtually any bike with a rear quick release!

Need to figure out if you have a thru axle or quick release? Check out this video: Quick Release vs Through Axle

  • The 125mm to 140mm size will fit all standard road and mountain bike sizes.
  • The 145mm size fits the majority of tandem bicycles.
  • The 160mm size fits the Santana tandem bicycles. This 160mm BOB QR is designed to work with the Santana Fork.

(Please Note: Quick release sizes do not indicate the length of the skewer, rather they indicate the width of the bicycle’s rear hub that the quick release is being mounted to. This is a measurement of the outside edge to outside edge of the hubs outer nuts that interface with the bicycle frame’s dropouts.)

Features

All BOB Quick Releases have reversible bushings for achieving a better fit with the BOB Trailer Fork.

Bob trailers can be attached to bicycles with wheel sizes between 20″ and 28″

Cargo capacity: 70 pounds (32 kilograms)

Specs

BOB QRRod Length: 165mm*Threaded Length: 32mmDropOut Inside Dimension: 126.5 – 140mm**Allowable Dropout Outside Dimension: 140 – 156mm

BOB 145 QRRod Length: 175mm*Threaded Length: 35mmDropOut Inside Dimension: 145mm**Allowable Dropout Outside Dimension: 145 – 164mm

BOB Santana QRRod Length: 190mm*Threaded Length: 30mmDropOut Inside Dimension: 160mm**Allowable Dropout Outside Dimension: 165 – 180mm

*Measurement is with QR lever in closed position**Dropout inside dimension (C) to measure the same as bicycle hubs axle over locknut dimensions

Warranty

5 years on frame and fork, 1 year on components.

Customer Reviews

4.8 Based on 5 reviews
5 ★
80%
4
4 ★
20%
1
3 ★
0%
0
2 ★
0%
0
1 ★
0%
0
Write a Review
  • Reviews

Thank you for submitting a review!

Your input is very much appreciated. Share it with your friends so they can enjoy it too!

MW
08/03/2018
Michael W.
CA

Bob Skewers

I found that ordering, receiving in the mail was expeditious. The only downfall was the end cost. Being a Canadian and paying the ultimate cost for items one needs. I still would consider looking at your online store for items that may be of interest. Thank you.

BB
08/21/2017
Bill B.
US

BOB trailer parts

This quick release fits perfect on my TREK excaliber 7 MTB

JG
07/20/2017
James G.
US

Correct Part Delivered On Time

Over all experience was good. I am an engineer so I don't tend to hyperbole.

KC
04/09/2014
Kenneth Colbert

BOB Trailer Quick Release

This is a must have item if you have a BoB Trailer. lost the one that came with it some how.So I needed a new one they sent it right out man was I every happy to get it.The Bike Trailer Shop is a great place to get parts that you need.I have order a few things from them before so I knew I would get what I order and they send you order to you pretty fast.Thanks Bike Trailer Shop.

AR
10/19/2012
Adam Robins

BOB Trailer Quick Release

Works well and exactly as described. The BOB trailer system is build around a few key components, and this may quite possibly be the most important of all of them. This thing just works and works well. It's and easy swap for any bike wheel already equipped with a skewer, taking less than a minute.

I bought this to go on my second bike, though when I do some touring I'll probably pop it out temporarily and take it along with me as a spare in case the one on my touring bike cracks or breaks.

Make sure when you buy one of these that you're buying the correct one for your dropout spacing.
