Surly Preamble Flat Bar – Milky Lemonade

$1,098.99

$125 shipping for bicycles priced under $1500 (within the lower 48).

SKU: SURPRML Categories: , , Tag:

Nothing More is Needed. Nothing Less Will Do.

The challenge was thus: Build a serious steel bike and give it only the attributes that matter most. Make it quick and comfortable on pavement, as well as confident and compliant on degraded surfaces. What the Enginerds put forth is Preamble, a pavement and gravel utility worker that proves you don’t need to cut corners or clip coupons to make a more affordable steel bike. You just need to keep shit simple.


Overview

Designed to introduce unfamiliar riders to Surly’s pavement and gravel line, Preamble highlights Surly’s most essential features: Durable custom steel tubing, a renowned ride feel, and just the right mounts for running racks, fenders, and bottle cages.

Available in flat-bar and drop-bar configurations, it’s disc-brake specific and shares a single-position vertical dropout with Surly Bridge Club. For new weekend riders and veteran commuters, Preamble makes it easier than ever to get out of the car and on top of tough and comfortable Chromoly steel.

Features

100% Surly Chromoly steel frame and fork; double-butted main triangle

Five frame sizes to fit nearly every size rider (XS, S, M, L, XL), with a slightly sloped top tube on XS and Small frames for improved standover and comfort

Friendly with 1x and 2x drivetrains

Mounts for racks, fenders, and two bottle cages (located on the seat tube and down tube)

Clearance for 650b x 41mm tires on XS–S frame sizes (650b x 38mm with fenders); 700c x 41mm tires on M–XL frame sizes (700c x 38mm with fenders)

Specs

frame geometry line drawing with letters

Frame measurements (mm) XS SM MD LG XL
A. Effective Top Tube 500 545 570 600 630
B. Stand Over 722 776 826 863 901
C. Reach 351 381 391 403 421
D. Stack 520 538 569 607 645
E. Total Seat Tube Length 410 505 565 605 645
F. Headtube Length 120 135 130 170 210
G. Headtube Angle 70 71 72 72 72
H. Seat Tube Angle 74 73 72.5 72 72
I. BB Drop 54 54 66 66 66
J. BB Height 285 285 293 293 293
K. Chainstay Length 420 420 435 435 435
L. Fork Length Axle to Crown 380 380 400 400 400
M. Fork Offset 47 47 44 44 44
N. Wheelbase 987 987 1030 1055 1085
Component measurements (mm)
Crank Arm Length 170 170 170 175 175
Handlebar Width 700 700 720 720 720
Stem Length 80 90 90 100 100

* All dimensions are preliminary and subject to change

Frameset

Frame: Surly Preamble — 100% Surly Chromoly steel, Natch tubing, double-butted main triangle, TIG welded, E.D. coated

Fork: Surly Preamble — 100% Surly Chromoly steel, Natch tubing, double-butted tapered fork blades, TIG welded, E.D. coated

Color: Milky Lemonade

Drivetrain

Front Derailleur: N/A

Rear Derailleur: Shimano Cues U4000 GS

Cassette: Shimano Cues LG400, 11–46t, 9-speed

Chain: Shimano LG500

Crankset: Shimano Cues U4000, 40T

Bottom Bracket: Shimano UN101, 68mm BSA

Shifter: Shimano Cues U4000

Brakes / Rotors: Tektro Hydraulic M275/276, 2-piston, Tektro 160/160mm Center Lock

Components

Headset: FSA Orbit MX

Stem: Kalloy AL, 31.8mm

Handlebar: Kalloy AL, 9° backsweep, 35mm rise

Grips: Velo Black

Seatpost: Kalloy 27.2 x 300mm — 0 offset (XS–MD), 12mm offset (LG–XL)

Saddle: WTB Volt Wide

Wheels

Front Hub: Shimano MT200, QR x 100mm, Center Lock, 32h

Rear Hub: Shimano QC400, QR x 141mm, Center Lock, 32h

Rims: Shining DB-21, 32h

Spokes: 14G Black

Tires: Teravail Washburn 650b x 35, 30 TPI, Wire Bead, Tan Sidewalls (XS–SM); Teravail Washburn 700c x 35, 30 TPI, Wire Bead, Tan Sidewalls (MD–XL)

Complete Bike Weight: 27 lb 7 oz (Medium)

Specifications subject to change without notice.

Warranty

Register your purchase at Surly’s Warranty Registration.

LIMITED WARRANTY FOR THE SURLY PREAMBLE

This Surly product is warranted against defects in materials and workmanship for three years from the date of retail purchase of the product, subject to the limitations detailed below. Save your dated receipt for proof of purchase.

This warranty does NOT cover the following:

  • Damage due to improper assembly or follow-up maintenance or lack of skill, competence or experience of the user or assembler
  • Products that have been modified, neglected, used in competition or for commercial purposes, misused or abused, involved in accidents or anything other than normal use
  • Installation of components, parts or accessories not originally intended for or compatible with bicycle as sold
  • Damage or deterioration to the paint, surface finish, aesthetics or appearance of the product
  • Normal wear and tear
  • Labor required to remove and/or refit and re-adjust the product within the bicycle assembly

This limited warranty is expressly limited to the repair or replacement of a defective product, at the option of Surly, and is the sole remedy of the warranty. This limited warranty applies only to the original purchaser of the Surly product and is not transferrable. This warranty applies only to products purchased through an authorized dealer or distributor. In no event shall Surly be liable for any loss, inconvenience or damage, whether direct, incidental, consequential, or otherwise resulting from breach of any express or implied warranty or condition, of merchantability, fitness for a particular purpose, or otherwise with respect to our products except as set forth herein.

This limited warranty gives the consumer specific legal rights, and those rights and other rights may vary from place to place. This limited warranty does not affect your statutory rights.

TO THE EXTENT NOT PROHIBITED BY LAW, THESE WARRANTIES ARE EXCLUSIVE AND THERE ARE NO OTHER EXPRESS OR IMPLIED WARRANTIES OR CONDITIONS INCLUDING WARRANTIES OR CONDITIONS OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE.
