Surly Midnight Special Frameset (Black Cherry Fizz)

Overview

The Midnight Special is an endurance road bike designed to provide comfort and speed on those all-day rides that extend well beyond fresh pavement.

It excels on pot-holed, deteriorating pavement and the occasional long stretch of gravel. The Midnight Special’s 700c tires eat up road chatter and absorb all the bumps in the road for a much more comfortable ride.

Features

100% Surly Chromoly frame, main triangle is double-butted; 1-1/8″ threadless Chromoly fork

Rack, fender, and three sets of water bottle mounts

Flat-Mount disc brakes

44mm head tube

Tire Clearance: 27.5 x 2.35″ (w/o fenders), 700c x 42mm (w/o fenders), 650b x 50 (w/ fenders), 700c x 38mm (w/ fenders)

Specs

frame geometry line drawing with letters

Frame measurements (mm)	40cm	46cm	50cm	54cm	56cm	58cm	60cm	64cm
A. Effective Top Tube	500	520	540	555	570	585	605	625
B. Stand Over	720	751	778	806	827	846	866	895
C. Reach	363	366	379	389	393	402	409	423
D. Stack	531	538	544	560	580	599	620	641
E. Total Seat Tube Length	400	460	500	540	560	580	600	640
F. Headtube Length	95	100	110	125	140	160	180	200
G. Headtube Angle	71.0	71.5	72.0	72.5	73.0	73.0	73.5	74.0
H. Seat Tube Angle	75.5	74.0	73.5	73.5	73.0	73.0	72.5	72.5
I. BB Drop	70	70	65	65	65	65	65	65
J. BB Height	–	–	–	–	–	–	–	–
K. Chainstay Length	425	425	425	425	425	425	425	425
L. Fork Length Axle to Crown	400	400	400	400	400	400	400	400
M. Fork Offset	50	50	50	50	50	50	50	50
N. Wheelbase	993	994	1007	1018	1012	1027	1036	1050

Component measurements (mm)
Crank Arm Length	165	165	170	170	170	175	175	175
Handlebar Width	400	400	420	440	440	460	460	460
Stem Length	70	80	80	100	100	120	120	120

* All dimensions are preliminary and subject to change

Fork Material: Carbon

Wheel Size: 700c , 650b

Brake Type: Disc

Platform: Midnight Special

Fork Type: Rigid

Rear Axle: 12mm Thru x 142mm

Frame Material: Steel

TT (Effective): 500

Mfg Size: 40

Front Axle: 12mm Thru x 100mm

Warranty

LIMITED WARRANTY FOR THE SURLY STRAGGLER

This Surly product is warranted against defects in materials and workmanship for three years from the date of retail purchase of the product, subject to the limitations detailed below. Save your dated receipt for proof of purchase.

This warranty does NOT cover the following:

Damage due to improper assembly or follow-up maintenance or lack of skill, competence or experience of the user or assembler
Products that have been modified, neglected, used in competition or for commercial purposes, misused or abused, involved in accidents or anything other than normal use
Installation of components, parts or accessories not originally intended for or compatible with bicycle as sold
Damage or deterioration to the paint, surface finish, aesthetics or appearance of the product
Normal wear and tear
Labor required to remove and/or refit and re-adjust the product within the bicycle assembly

This limited warranty is expressly limited to the repair or replacement of a defective product, at the option of Surly, and is the sole remedy of the warranty. This limited warranty applies only to the original purchaser of the Surly product and is not transferrable. This warranty applies only to products purchased through an authorized dealer or distributor. In no event shall Surly be liable for any loss, inconvenience or damage, whether direct, incidental, consequential, or otherwise resulting from breach of any express or implied warranty or condition, of merchantability, fitness for a particular purpose, or otherwise with respect to our products except as set forth herein.

This limited warranty gives the consumer specific legal rights, and those rights and other rights may vary from place to place. This limited warranty does not affect your statutory rights.

TO THE EXTENT NOT PROHIBITED BY LAW, THESE WARRANTIES ARE EXCLUSIVE AND THERE ARE NO OTHER EXPRESS OR IMPLIED WARRANTIES OR CONDITIONS INCLUDING WARRANTIES OR CONDITIONS OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE.
