Overview
The Midnight Special is an endurance road bike designed to provide comfort and speed on those all-day rides that extend well beyond fresh pavement. It excels on pot-holed, deteriorating pavement and the occasional long stretch of gravel. The Midnight Special’s 700c tires eat up road chatter and absorb all the bumps in the road for a much more comfortable ride.
Features
100% Surly Chromoly frame, main triangle is double-butted; 1-1/8″ threadless Chromoly fork
Rack, fender, and three sets of water bottle mounts
Flat-Mount disc brakes
44mm head tube
Tire Clearance: 27.5 x 2.35″ (w/o fenders), 700c x 42mm (w/o fenders), 650b x 50 (w/ fenders), 700c x 38mm (w/ fenders)
Specs
| Frame measurements (mm) | 40cm | 46cm | 50cm | 54cm | 56cm | 58cm | 60cm | 64cm |
|---|---|---|---|---|---|---|---|---|
| A. Effective Top Tube | 500 | 520 | 540 | 555 | 570 | 585 | 605 | 625 |
| B. Stand Over | 720 | 751 | 778 | 806 | 827 | 846 | 866 | 895 |
| C. Reach | 363 | 366 | 379 | 389 | 393 | 402 | 409 | 423 |
| D. Stack | 531 | 538 | 544 | 560 | 580 | 599 | 620 | 641 |
| E. Total Seat Tube Length | 400 | 460 | 500 | 540 | 560 | 580 | 600 | 640 |
| F. Headtube Length | 95 | 100 | 110 | 125 | 140 | 160 | 180 | 200 |
| G. Headtube Angle | 71.0 | 71.5 | 72.0 | 72.5 | 73.0 | 73.0 | 73.5 | 74.0 |
| H. Seat Tube Angle | 75.5 | 74.0 | 73.5 | 73.5 | 73.0 | 73.0 | 72.5 | 72.5 |
| I. BB Drop | 70 | 70 | 65 | 65 | 65 | 65 | 65 | 65 |
| J. BB Height | – | – | – | – | – | – | – | – |
| K. Chainstay Length | 425 | 425 | 425 | 425 | 425 | 425 | 425 | 425 |
| L. Fork Length Axle to Crown | 400 | 400 | 400 | 400 | 400 | 400 | 400 | 400 |
| M. Fork Offset | 50 | 50 | 50 | 50 | 50 | 50 | 50 | 50 |
| N. Wheelbase | 993 | 994 | 1007 | 1018 | 1012 | 1027 | 1036 | 1050 |
| Component measurements (mm) | ||||||||
| Crank Arm Length | 165 | 165 | 170 | 170 | 170 | 175 | 175 | 175 |
| Handlebar Width | 400 | 400 | 420 | 440 | 440 | 460 | 460 | 460 |
| Stem Length | 70 | 80 | 80 | 100 | 100 | 120 | 120 | 120 |
* All dimensions are preliminary and subject to change
Frameset
Frame
Surly Midnight Special 4130 Chromoly, Natch tubing, double-butted main triangle, TIG welded, ED coated
Fork
Surly Midnight Special 4130 Chromoly, Natch tubing, TIG welded, brazed lugs, ED coated
Drivetrain
Front Derailleur
Shimano Tiagra R4000
Rear Derailleur
Shimano Tiagra R4000
Cassette
Shimano CUES RS400, 11-36t, 11-speed
Chain
Shimano LG500
Crankset
Shimano Tiagra R4000, 50-34t
Bottom Bracket
Shimano RS501 BSA
Shifter
Shimano Tiagra R4020
Brakes
Brake Levers
Shimano Tiagra R4020
Brake Calipers
Shimano Tiagra R4020
Rotors
Shimano RT26, 160/160mm, 6-bolt
Components
Headset
FSA Orbit ITA
Stem
Teravail Radia
Handlebar
Teravail Radia
Grips / Bar Tape
Velo Black Cork
Seatpost
Promax SP-2019, 12mm offset on sizes 54–64
Saddle
WTB Volt Medium, Steel
Wheels
Front Hub
Novatec 12 x 100mm, thru-axle
Rear Hub
Novatec 12 x 142mm, thru-axle
Spokes
DT Swiss Champion 14G
Rims
Alex Adventurer 2, 700c, 32h
Tires
Teravail Rampart 700c x 35mm, Durable, Tubeless Ready
Pedals
N/A
Complete Bike Weight
25 lb 15 oz, size 56cm
Specifications are subject to change without notice.
Warranty
Register your purchase at Surly’s Warranty Registration.
LIMITED WARRANTY FOR THE SURLY MIDNIGHT SPECIAL
This Surly product is warranted against defects in materials and workmanship for three years from the date of retail purchase of the product, subject to the limitations detailed below. Save your dated receipt for proof of purchase.
This warranty does NOT cover the following:
- Damage due to improper assembly or follow-up maintenance or lack of skill, competence or experience of the user or assembler
- Products that have been modified, neglected, used in competition or for commercial purposes, misused or abused, involved in accidents or anything other than normal use
- Installation of components, parts or accessories not originally intended for or compatible with bicycle as sold
- Damage or deterioration to the paint, surface finish, aesthetics or appearance of the product
- Normal wear and tear
- Labor required to remove and/or refit and re-adjust the product within the bicycle assembly
This limited warranty is expressly limited to the repair or replacement of a defective product, at the option of Surly, and is the sole remedy of the warranty. This limited warranty applies only to the original purchaser of the Surly product and is not transferrable. This warranty applies only to products purchased through an authorized dealer or distributor. In no event shall Surly be liable for any loss, inconvenience or damage, whether direct, incidental, consequential, or otherwise resulting from breach of any express or implied warranty or condition, of merchantability, fitness for a particular purpose, or otherwise with respect to our products except as set forth herein.
This limited warranty gives the consumer specific legal rights, and those rights and other rights may vary from place to place. This limited warranty does not affect your statutory rights.
TO THE EXTENT NOT PROHIBITED BY LAW, THESE WARRANTIES ARE EXCLUSIVE AND THERE ARE NO OTHER EXPRESS OR IMPLIED WARRANTIES OR CONDITIONS INCLUDING WARRANTIES OR CONDITIONS OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE.
