Surly Krampus Frameset 29″

$998.99

SKU: SURKM29 Categories: , Tag:

The Krampus is the bike that started it all — the plus-size movement that is. For 2017, the Krampus features Surly’s Gnot-Boost rear hub spacing of 145mm; compatible with Boost 148 x 12mm thru-axle, 142 x 12mm thru-axle and 135mm quick-release hubs.


Overview

Our inspiring review is coming soon, for now here is what Surly says:

Breaking the Mold with a 29er Bike

As the first “plus” bike to hit the market, Krampus changed the way many people approach trail riding. It’s shown people the light of how high volume, large diameter tires can vastly improve the ride experience. It’s also done a bang-up job dispelling the myth that big tires make you slow.

Krampus is kind of like the opposite of a mullet: long in the front and short in the rear. With a long toptube and compact chainstays, it takes trail-shredding abilities to the next level. A mullet may be business in the front, party in the back but Krampus makes partying its business.

Features

  • Max Tire Clearance: Designed to fit up to 29 x 3.0” tires
  • Fork Material: Steel
  • Color: Yellow
  • Wheel Size: 29+
  • Front Axle: 15mm Thru x 110mm
  • Brake Type: Disc
  • Platform: Krampus
  • Fork Type: Rigid
  • Frame Material: Steel
  • TT (Effective): 637
  • Size: Large
  • Rear Axle: 12mm Thru x 145mm
  • Frame Type: Rigid

Specs

SIZE SM MD LG XL
Reach 404 426 448 470
Stack 593 602 612 621
Head Tube Angle 69.0° 69.0° 69.0° 69.0°
Head Tube Length 90 100 110 120
Seat Tube Length 368 419 470 521
BB Drop 65 65 65 65
Wheelbase 1087 1113 1138 1164
Chainstay Length 435 435 435 435
Top Tube Length, Actual 556.8 573 595.1 621.8
Top Tube Length, Effective 585 610 635 660
Seat Tube Angle 73.0° 73.0° 73.0° 73.0°
Standover Height 770 797 825 853
Stem Length 70 70 70 80
Stem Angle
Handlebar Width 750 800 800 800
Crank Length 170 175 175 175
Fork Length 483 483 483 483
Fork Rake 47 47 47 47
*Standover is measured from the top of the TT, at the center, with a tire measuring approximately Ø773mm



Warranty

All Surly frames are backed by a 3-year warranty against defects in material and manufacturing.  Please see Surly’s frame warranty page to review their limitations.
