Overview
The Largest Tire Clearance on a Fat Bike Frame
While we could certainly throw out terms like “confidence-inspiring” and “traction-laden” to describe Ice Cream Truck, those phrases are mostly bullshit, so we’re not going to do that. We’re not here to inspire you, and we didn’t laden it with anything. What we did do was design a monolith of a trail bike that doesn’t give two shits about what’s in front of it.
Features
Long toptube, short seatstays, and a 68-degree headtube angle makes it tight and maneuverable on fast, technical terrain
Modern trail bike standards like stealth dropper post routing, 44mm headtube, and thru-axles
Clearance for a full 26” x 5” tire on 100mm rims
Specs
| Size | Small | Medium | Large | X-Large |
|---|---|---|---|---|
| A. Effective Top Tube | 585.0 | 610.0 | 635.0 | 660.0 |
| B. Stand Over | 777.0 | 803.0 | 831.0 | 860.0 |
| C. Reach | 405.0 | 427.0 | 449.0 | 472.0 |
| D. Stack | 588.0 | 598.0 | 607.0 | 616.0 |
| E. Total Seat Tube Length | 366.0 | 419.0 | 470.0 | 521.0 |
| F. Headtube Length | 95.0 | 105.0 | 115.0 | 125.0 |
| G. Headtube Angle |
68.0
|
68.0
|
68.0
|
68.0
|
| H. Seat Tube Angle |
73.0
|
73.0
|
73.0
|
73.0
|
| I. BB Drop | 60.0 | 60.0 | 60.0 | 60.0 |
| K. Chainstay Length | 440.0 | 440.0 | 440.0 | 440.0 |
| L. Fork Length Axle to Crown | 483.0 | 483.0 | 483.0 | 483.0 |
| M. Fork Offset | 47.0 | 47.0 | 47.0 | 47.0 |
| N. Wheelbase | 1105.0 | 1131.0 | 1157.0 | 1182.0 |
| Crank Arm Length | 165.0 | 170.0 | 170.0 | 170.0 |
| Handlebar Width | 750.0 | 800.0 | 800.0 | 800.0 |
| Recommended Rider Height | 162.0 – 173.0 | 170.0 – 183.0 | 180.0 – 190.0 | 188.0 – 198.0 |
| Stem Length | 60.0 | 70.0 | 80.0 | 90.0 |
Frameset
Frame: Surly Ice Cream Truck, 4130 Chromoly (Natch tubing), double-butted main triangle, TIG welded, ED coated
Fork: Surly Ice Cream Truck, 4130 Chromoly (Natch tubing), double-butted tapered fork blades, TIG welded, ED coated
Components
Headset: FSA Orbit ITA
Seatpost Clamp: Stainless 33.1 collar (Black)
Seatpost: Promax SP-2019, 0 offset, 400mm length
Stem: Promax DA-296, 31.8mm
Grips/Bar Tape: Velo (Black)
Saddle: WTB Volt
Handlebar: Salsa Rustler, 31.8mm
Drivetrain
Front Derailleur: N/A
Rear Derailleur: Shimano Deore M6100 SGS
Cassette: Shimano Deore M6100, 10–51t (12-speed)
Chain: KMC X12 EPT Anti-Rust
Crankset: Race Face Ride, 30T
Shifter: Shimano Deore M6100
Brake Levers: Tektro HD-M3520
Brake Calipers: Tektro HD-M3520 (2-piston)
Bottom Bracket: Race Face BSA
Rotors: Tektro 180mm (front) / 160mm (rear), 6-bolt
Wheels
Front Tire: Surly Lou, 26 x 4.8″, 120tpi, tubeless ready
Rear Tire: Surly Bud, 26 x 4.8″, 120tpi, tubeless ready
Front Hub: Novatec, 15 x 150mm
Rear Hub: Novatec, 12 x 197mm
Rims: Surly My Other Brother Daryl, 32h
Weight
Complete Bike (Medium): 35 lb 2 oz
Warranty
Register your purchase at Surly’s Warranty Registration.
LIMITED WARRANTY
This Surly product is warranted against defects in materials and workmanship for three years from the date of retail purchase of the product, subject to the limitations detailed below. Save your dated receipt for proof of purchase.
This warranty does NOT cover the following:
- Damage due to improper assembly or follow-up maintenance or lack of skill, competence or experience of the user or assembler
- Products that have been modified, neglected, used in competition or for commercial purposes, misused or abused, involved in accidents or anything other than normal use
- Installation of components, parts or accessories not originally intended for or compatible with bicycle as sold
- Damage or deterioration to the paint, surface finish, aesthetics or appearance of the product
- Normal wear and tear
- Labor required to remove and/or refit and re-adjust the product within the bicycle assembly
This limited warranty is expressly limited to the repair or replacement of a defective product, at the option of Surly, and is the sole remedy of the warranty. This limited warranty applies only to the original purchaser of the Surly product and is not transferrable. This warranty applies only to products purchased through an authorized dealer or distributor. In no event shall Surly be liable for any loss, inconvenience or damage, whether direct, incidental, consequential, or otherwise resulting from breach of any express or implied warranty or condition, of merchantability, fitness for a particular purpose, or otherwise with respect to our products except as set forth herein.
This limited warranty gives the consumer specific legal rights, and those rights and other rights may vary from place to place. This limited warranty does not affect your statutory rights.
TO THE EXTENT NOT PROHIBITED BY LAW, THESE WARRANTIES ARE EXCLUSIVE AND THERE ARE NO OTHER EXPRESS OR IMPLIED WARRANTIES OR CONDITIONS INCLUDING WARRANTIES OR CONDITIONS OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE.
