Surly Disc Trucker, 26″ (Grandpa’s Khakis)

$2,098.99

Free shipping on bicycles priced over $2000 (within the lower 48).

SKU: SUR26GR Categories: , Tag:

Why Disc Brake Touring Bikes?

Disc Trucker enjoys the same reputation as Long Haul Trucker: It’s one of the best-riding and most value-packed drop bar touring bikes out there. Sometimes, however, a combination of load, climate, and terrain demands a bit more braking performance than a standard rim-brake LHT can provide.

That’s where the newly redesigned Disc Trucker comes in. Packing reliable stopping power and a horde of useful mounting points, shortened chainstays up the Disc Trucker’s stiffness and maneuverability around corners. Add in improved fit and handling under load, plus captured thru-axles for tool-free removal and installation, and the Disc Trucker is ready to help you meet — or dodge — your daily obligations.


Overview

A class-leading touring bike, the newly redesigned Disc Trucker provides versatility and dependability on the daily commute or trans-continental excursion. Fork blade three-pack mounts enable you to attach and haul even more stuff, and the frame features a low bottom bracket and long chainstays for comfort and stability while loaded down. With increased stack height and improved stand-over clearance, plus ample space for larger tires and fenders, it’s designed to go the distance.

Features

100% Chromoly steel frame and fork; double-butted main triangle and E.D. coating for increased frame life

Braze-ons for fenders, racks, and almost anything else you might want to stick on your bike, plus spare spoke holders for when the road gets rough

Fork blade three-pack mounts for even more mounting options, plus routing for Dynamo hubs

Redesigned front and rear dropouts to accommodate captured 12mm thru-axles and flat-mount disc brakes

Clearance for 26 x 2.1″ tires with or without fenders

Specs

Frame measurements (mm) 42cm 46cm 50cm 52cm 54cm
A. BB Drop 50 50 50 50 50
B. Chainstay Length 450 450 450 450 450
C. Fork Length – Axle to Crown 376 376 376 376 376
D. Fork Offset 45 45 45 45 45
E. Head Tube Angle (deg) 70 70 71 71 71
F. Headtube Length 125 130 170 185 205
G. Reach 362 371 369 374.5 378
H. Seat Tube Angle (deg) 75.0 74.5 74.0 73.5 73.0
I. Seat Tube Length – Center to Top 420 460 500 520 540
J. Stack 515 520 561 575.5 594.5
K. Standover 710 731 766 782 800
L. Top Tube Length (Effective) 500 515 530 545 560
M. Wheelbase 1026 1037 1040 1050 1060.5
Component measurements (mm)
Crank Arm Length 170 170 170 170 170
Handlebar Width 420 420 420 450 450
Handlebar Rise / Drop 30 30 30 30 30
Stem Length 70 70 70 90 100
Stem Angle (deg) 6 6 6 6 6

Frameset

Frame: Surly Disc Trucker — 100% Surly Chromoly steel, Natch tubing, double-butted main triangle, TIG welded, E.D. coated

Fork: Surly Disc Trucker — 100% Surly Chromoly steel, Natch tubing, double-butted tapered fork blades, brazed lugs, E.D. coated

Color: Grandpa’s Khakis

Drivetrain

Front Derailleur: Shimano CUES U6030

Rear Derailleur: Shimano CUES U6020 SGS

Cassette: Shimano CUES LG400, 11–39t, 10-speed

Chain: Shimano LG500

Crankset: Shimano CUES U6000, 46/30T

Bottom Bracket: Shimano UR400 BSA

Shifter: Shimano CUES U6030

Brakes / Rotors: Shimano CUES U6030, Shimano RT26 180/180mm, 6-bolt

Components

Headset: FSA Orbit MX

Stem: Promax DA-296, 31.8mm

Handlebar: Surly Truckstop

Grips / Bar Tape: Velo Black Cork

Seatpost: Promax 27.2 x 350mm

Saddle: WTB Volt Wide

Wheels

Front Hub: Novatec 12 x 100mm, 6-bolt, 36h

Rear Hub: Novatec 12 x 142mm, 6-bolt, 36h

Rims: Alex Adventurer 2, 26″, 36h

Tires: Surly ExtraTerrestrial 26″ x 46mm, 60 TPI

Spokes: 14G Black

Complete Bike Weight: 28 lb 7 oz (52cm)

Specifications subject to change without notice.

Warranty

Register your purchase at Surly’s Warranty Registration.

LIMITED WARRANTY FOR THE SURLY DISC TRUCKER

This Surly product is warranted against defects in materials and workmanship for three years from the date of retail purchase of the product, subject to the limitations detailed below. Save your dated receipt for proof of purchase.

This warranty does NOT cover the following:

  • Damage due to improper assembly or follow-up maintenance or lack of skill, competence or experience of the user or assembler
  • Products that have been modified, neglected, used in competition or for commercial purposes, misused or abused, involved in accidents or anything other than normal use
  • Installation of components, parts or accessories not originally intended for or compatible with bicycle as sold
  • Damage or deterioration to the paint, surface finish, aesthetics or appearance of the product
  • Normal wear and tear
  • Labor required to remove and/or refit and re-adjust the product within the bicycle assembly

This limited warranty is expressly limited to the repair or replacement of a defective product, at the option of Surly, and is the sole remedy of the warranty. This limited warranty applies only to the original purchaser of the Surly product and is not transferrable. This warranty applies only to products purchased through an authorized dealer or distributor. In no event shall Surly be liable for any loss, inconvenience or damage, whether direct, incidental, consequential, or otherwise resulting from breach of any express or implied warranty or condition, of merchantability, fitness for a particular purpose, or otherwise with respect to our products except as set forth herein.

This limited warranty gives the consumer specific legal rights, and those rights and other rights may vary from place to place. This limited warranty does not affect your statutory rights.

TO THE EXTENT NOT PROHIBITED BY LAW, THESE WARRANTIES ARE EXCLUSIVE AND THERE ARE NO OTHER EXPRESS OR IMPLIED WARRANTIES OR CONDITIONS INCLUDING WARRANTIES OR CONDITIONS OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE.
