Features

High-modulus carbon fiber frame soaks up road chatter for a smooth, compliant ride.

Salsa’s Class 5™ VRS (Vibration Reduction System) has seatstays and chainstays shaped to promote vertical compliance and lateral stiffness for a smooth and straight-tracking ride.

RockShox Rudy XPLR 40mm gravel suspension fork for ultimate comfort and control on harsh gravel terrain

Suspension-corrected to fit 40mm gravel bike suspension forks

Progressive geometry with a long reach and short stem. A low bottom bracket and slack head tube angle maximize stability and confidence. Short chainstays offer responsive handling, and symmetrical dropped chainstays combined with a steep seat tube angle deliver excellent power transfer.

Top tube bag mounts, generous bottle capacity, direct-mount frame bag mounts, rack and fender mounts.

Through-headset cable routing keeps cockpits clean and keeps hoses and housing out of the way of handlebar bags and accessories.

Flyway can fit a 700c x 50mm tire in the frame

Specs

Frame measurements (mm)	XS	SM	MD	ML	LG	XL
A. Effective Top Tube	510	535	555	575	600	620
B. Stand Over	382	715	749	780	814	843
C. Reach	375	388	392	405	421	435
D. Stack	541	550	569	592	625	644
E. Total Seat Tube Length	390	430	470	505	540	575
F. Headtube Length	90	100	120	145	180	200
G. Headtube Angle	70.5	70.5	70.5	70.5	70.5	70.5
H. Seat Tube Angle	76.0	75.0	74.0	74.0	74.0	74.0
I. BB Drop	76	76	76	76	76	76
J. BB Height	283	283	283	283	283	283
K. Chainstay Length	425	425	425	425	425	425
L. Fork Length Axle to Crown	420	420	420	420	420	420
M. Fork Offset	51	51	51	51	51	51
N. Wheelbase	1012	1028	1039	1060	1088	1109
Component measurements (mm)
Crank Arm Length	160	165	165	170	170	175
Handlebar Width	400	400	420	440	440	460
Stem Length	60	60	70	80	90	100

* All dimensions are preliminary and subject to change

Frame & Fork

Frame: Flyway Carbon

Fork: RockShox Rudy XPLR, 40mm travel

Color: Blackberry

Drivetrain

Shifters: SRAM Rival AXS HRD

Rear Derailleur: SRAM Rival XPLR AXS

Cassette: SRAM Rival XPLR, 10–46T

Chain: SRAM Rival XPLR

Crankset: SRAM Rival XPLR

Bottom Bracket: SRAM DUB T47 Internal

Front Derailleur: N/A

Brakes

Brakes: SRAM Rival AXS HRD (levers + calipers)

Rotors: SRAM, 160mm front / 160mm rear

Cockpit & Components

Handlebar: Teravail Feldspar Carbon

Grips / Bar Tape: Velo anti-slip

Stem: Teravail Radia

Headset: FSA CRII

Seatpost: TranzX YSI20 dropper post

• XS–SM: 100mm travel
• MD–XL: 125mm travel

Saddle: WTB Gravelier

Wheels & Tires

Rims: WTB Proterra Light i25

Hubs: WTB (front & rear)

Tires: Teravail Updraft, 700c × 50mm

Specifications subject to change without notice.

Warranty

LIMITED WARRANTY

Salsa Cycles ( “Salsa ” ) makes the following limited Warranty:

All Salsa products are warranted against manufacturing defects in materials and workmanship from the date of retail purchase of the product, subject to the limitations detailed below. Every Salsa frame, component, and apparel has a useful product life cycle. The length of that useful product life cycle will vary depending on the construction and the materials of the product, maintenance and care the product receives, and the amount and type of use the product is subjected to over its life. Your bike has an intended level of use as defined by the ASTM Riding Condition Classification Chart. Failure to adhere to the use cases identified in this chart will void your warranty. Save your dated receipt for proof of purchase.

NOTE:
All warranty periods below apply to the original owner only

ONE YEAR WARRANTY

All apparel
All frame bags

Salsa Cycles does not guarantee the compatibility of original components with a warranty replacement frame. Salsa Cycles is not responsible for parts or labor required to remove and/or refit and re-adjust the product within the bicycle assembly, including wheel rebuilds.

Salsa Cycles cannot guarantee a color match to the original frame, component, or apparel in the event of a replacement.

This warranty applies to 2014 and newer model bicycles and covers only Salsa Cycles branded product. Any other original part or component shall be covered by the stated warranty of the original manufacturer. Any products not specifically included above are hereby excluded.

TWO YEAR WARRANTY

Aluminum chainstays of suspension frames
Aluminum seatstays of suspension frames
Carbon seatstays of suspension frames
All other suspension frame parts (excludes hanger, pivot hardware, bearings)

THREE YEAR WARRANTY

Aluminum frames
Aluminum front triangles of suspension frames
All Salsa forks
All Salsa components

FIVE YEAR WARRANTY

Steel frames
Titanium frames
Carbon frames
Carbon front triangle of suspension frames

THE WARRANTY DOES NOT COVER THE FOLLOWING

Damage due to improper assembly or follow-up maintenance or lack of skill, competence or experience of the user or assemble

Bicycles that were not assembled or serviced by an authorized Salsa Cycles dealer

Products that have been modified, neglected, used in competition, or for commercial purposes such as rental, courier, police, security, etc, misused or abused, involved in accidents or anything other than normal use

Installation of components, parts, or accessories not originally intended for use with or compatible with Salsa frames and components

Salsa Cycles bicycles, frames, components or softgoods purchased from an unauthorized dealer

Salsa Cycles bicycles, frames, components or softgoods purchased from third-party internet sites, including auction websites, and regional trading websites (examples: Amazon, eBay, and Craigslist) are not covered under this warranty, even if you have a receipt

Sandblasting, sanding, grinding, wire brushing, filing, welding, brazing, drilled holes, anodizing, refinishing, powder coating, or chrome plating the bicycle, frame, or component will void the warranty

Internal rust perforation on all steel frames

Wear, scratches, chips and cracks to paint, finish, or coating on all Salsa frames and components

Bent or broken derailleur hangers or Alternator plates

Labor required to remove and/or refit and re-adjust the product within the bicycle assembly, including wheel rebuilds

Damage to carbon fiber caused by any carbon assembly paste

Normal wear and tear

LEGAL DISCLAIMER

This limited warranty is expressly limited to the repair or replacement of a defective product, at the option of Salsa Cycles, and is the sole remedy of the warranty. This limited warranty applies only to the original purchaser of the Salsa Cycles product and is not transferable. This warranty applies only to Salsa Cycles products purchased through an authorized dealer or distributor. In no event shall Salsa Cycles be liable for any loss, inconvenience or damage, whether direct, incidental, consequential, or otherwise resulting from breach of any express or implied warranty or condition of merchantability, fitness for a particular purpose, or otherwise with respect to our products except as set forth herein. This warranty gives the consumer specific legal rights, and those rights and other rights may vary from place to place. This warranty does not affect your statutory rights.

TO THE EXTENT NOT PROHIBITED BY LAW, THESE WARRANTIES ARE EXCLUSIVE AND THERE ARE NO OTHER EXPRESS OR IMPLIED WARRANTIES OR CONDITIONS INCLUDING WARRANTIES OR CONDITIONS OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE.

For 2013 and older model bicycles and products, please consult your Owner’s Manual, Salsa Cycles product instructions, or contact Salsa Cycles or your authorized Salsa dealer for the applicable warranty information.
