Overview
With bigger bikes, there comes bigger demands, but thankfully not always of your wallet. The new 35 is the perfect choice for both MTBs and E-MTBs alike with a ton of built-in value. A fork that will not only look the part for burly enduro/trail bikes but will also back up its looks with a great high performance-to-value package.
Features
Burly 35mm chassis for added stiffness and steering precision
DebonAir air spring reduces friction from every single moving part improving bump absorption and response under load
Fits Tires up to 2.8″ (without fenders; the use of a full fender will reduce tire clearance)
Specs
130 mm Fork
Spring System
-
Positive Spring: Air
-
Negative Spring: Air
Wheel & Compatibility
-
Wheel Size: 27.5″
-
Designed for E-Bike Use: Yes
-
Maximum Tire Width: 81 mm
Chassis & Fit
-
Stanchion Diameter: 35 mm
-
Steerer Type: Tapered
-
Steerer Tube Length: 265 mm
-
Crown Race: 40
-
S.H.I.S. Stem Clamp Diameter: 28.6 mm
Axle & Brakes
-
Front Axle: 15 x 110 mm Thru-Axle
-
Brake Mount: Post Mount 180
Adjustments
-
External Adjustments:
-
Low-Speed Compression
-
Lockout Threshold
-
Rebound
-
-
Lockout Switch: Crown
Geometry
-
Travel: 130 mm
-
Offset: 44 mm
-
Axle-to-Crown: 528 mm
Finish & Weight
-
Color: Gloss Black
-
Weight: 2259 g
140 mm Travel Fork
Spring System
-
Positive Spring: Air
-
Negative Spring: Air
Wheel & Compatibility
-
Wheel Size: 27.5″
-
Designed for E-Bike Use: Yes
-
Maximum Tire Width: 81 mm
Chassis & Fit
-
Stanchion Diameter: 35 mm
-
Steerer Type: Tapered
-
Steerer Tube Length: 265 mm
-
Crown Race: 40
-
S.H.I.S. Stem Clamp Diameter: 28.6 mm
Axle & Brakes
-
Front Axle: 15 x 110 mm Thru-Axle
-
Brake Mount: Post Mount 180
Adjustments
-
External Adjustments:
-
Low-Speed Compression
-
Lockout Threshold
-
Rebound
-
-
Lockout Switch: Crown
Geometry
-
Travel: 140 mm
-
Offset: 44 mm
-
Axle-to-Crown: 538 mm
Finish & Weight
-
Color: Gloss Black
-
Weight: 2259 g
