Otso Warakin Ti

Features

Titanium ride feel: Smooth, lively, and built for years of rough-road use

Bikepacking-ready fork: Triple mounts add room for cages or extra gear

Mixed-surface confidence: 700 x 45 tires balance speed, comfort, and grip

Personalized build options: Cockpit sizing, headset colors, and chainring choices let riders dial in the bike

Adventure-ready platform: Durable frame, reliable wheels, and wide-range drivetrain options make it ready for long days beyond pavement



Specs

Most components can be customized at time of order, contact us!

Shared Specs Across All Builds

Frame
Warakin 3Al-2.5V B338 grade 9 titanium frame with internally butted front triangle

Fork
Lithic Hiili 420 full carbon fork with triple mounts, 12mm thru-axle

Headset
Wolf Tooth Performance Headset, ZS44/EC44, black
Option to upgrade to Wolf Tooth Premium Headset with color choices

Handlebar
Lithic Aventurine with custom width options

Bar Tape
Anti-Slip Gel Bar Tape

Stem
Aluminum 31.8mm with custom length and upgrade options

Seatpost
Aluminum, 27.2 x 350mm, 8mm offset
Custom upgrade options available

Seatpost Clamp
Wolf Tooth 31.8mm, black
Custom color options available with headset upgrade

Saddle
WTB Silverado Medium, steel rails, 142 x 265mm

Wheels
DT Swiss G 1800, 24mm inner width
100 x 12mm thru-axle front
142 x 12mm thru-axle rear
Custom upgrade options available

Tires
Schwalbe G-One RS Pro, 700 x 45, black
Custom upgrade options available

Shimano GRX 600

Rear Derailleur
Shimano GRX 822 1x, 12-speed

Shifters
Shimano GRX 600 mechanical, 12-speed

Cassette
Shimano SLX M7100, 10-51T, 12-speed

Brake Calipers
Shimano RX400 hydraulic

Cranks
Shimano GRX 800, 170mm
Custom Wolf Tooth chainring size options

Bottom Bracket
Shimano English threaded BSA, Ø68mm

Chain
Shimano 12-speed

Shimano GRX 800 Di2 1×12

Rear Derailleur
Shimano GRX 827 Di2 1x, 12-speed

Shifters
Shimano GRX 825 Di2 2x, 12-speed

Cassette
Shimano XT M8100, 10-51T, 12-speed

Brake Calipers
Shimano RX800 hydraulic

Cranks
Shimano GRX 800, 170mm
Custom Wolf Tooth chainring options

Bottom Bracket
Shimano English threaded BSA, Ø68mm

Chain
Shimano 12-speed

SRAM Apex Mechanical

Rear Derailleur
SRAM Apex Eagle mechanical, 12-speed

Shifters
SRAM Apex, 12-speed

Cassette
SRAM NX, 11-50T, HG, 12-speed

Brake Calipers
SRAM Apex hydraulic

Cranks
SRAM Apex Wide, 170mm, 42T chainring

Bottom Bracket
SRAM DUB English threaded BSA, Ø68mm

Chain
SRAM NX Eagle 12-speed

SRAM Rival XPLR AXS 1×13

Rear Derailleur
SRAM Rival XPLR AXS E1, 13-speed

Shifters
SRAM Rival AXS HRD E1

Cassette
SRAM XG-1351, 10-46T

Brake Calipers
SRAM Rival hydraulic

Cranks
SRAM Rival XPLR Wide E1, 170mm, 42T
Custom Wolf Tooth chainring options

Bottom Bracket
SRAM DUB English threaded BSA, Ø68mm

Chain
SRAM Rival Road Flattop, 12/13-speed

SRAM Force XPLR AXS 1×13

Rear Derailleur
SRAM Force XPLR AXS E1, 13-speed

Shifters
SRAM Force AXS HRD E1

Cassette
SRAM XG-1371, 10-46T

Brake Calipers
SRAM Force hydraulic

Cranks
SRAM Force XPLR Wide E1, 42T
Custom crank length and Wolf Tooth chainring options

Bottom Bracket
SRAM DUB English threaded BSA, Ø68mm

Chain
SRAM Force Road Flattop, 12/13-speed

Size	49cm	52cm	54cm	56cm	58cm	60cm
Recommended rider height	5’0″-5’2″	5’2″-5’4″	5’4″-5’8″	5’8″-6’0″	6’0″-6’2″	6’2″-6’5″
Recommended rider inseam	27″-29″	28″-30″	30″-33″	32″-34″	33″-35″	34″-37″
Stack	540mm	549mm	570mm	596mm	622mm	641mm
Reach	365	378mm	381mm	383mm	384mm	392mm
Standover	730mm	760mm	780mm	800mm	820mm	840 mm
Effective top tube	510mm	530mm	545mm	565mm	580mm	600mm
Head tube angle	70°	70.5°	71°	71.5°	72°	72°
Head tube length	87mm	95mm	115mm	140mm	165mm	185mm
Seat tube angle	75°	74.5°	74°	73°	72.5°	72°
Seat tube length	470mm	505mm	530mm	550mm	570mm	590mm
BB drop	70mm	70mm	70mm	70mm	70mm	70mm
Chainstay length	430mm	430mm	430mm	430mm	430mm	430mm
Wheelbase	1011	1022	1028	1033	1037	1046
Trail	72mm	71mm	70mm	67.5mm	65mm	65mm
Fork offset	47mm	47mm	47mm	47mm	47mm	47mm
Rigid fork axle to crown length	420mm	420mm	420mm	420mm	420mm	420mm

Warranty

• All Otso frames are warranted against defects in materials and workmanship for 5 years from the date of retail purchase.
• This warranty applies to the original owner only and is not transferable.
• Please keep your sales receipt or order number for any warranty claims to ensure a quick resolution.

What’s Not Covered:

• Damage from improper assembly, maintenance, or user/assembler inexperience.
• Modifications, neglect, misuse, competition, commercial use, or accidents.
• Installation of incompatible components, parts, or accessories.
• Normal wear and tear, or damage to paint, surface finish, or aesthetics.
• Compatibility of original components with a replacement frame is not guaranteed.
• Costs for labor, parts removal, refitting, or re-adjustment, including wheel rebuilds.

Claim Process:

• Warranty claims are limited to the repair or replacement of the defective frame, at Otso’s discretion.
• This warranty does not cover incidental or consequential damages.

Legal Information:

• This warranty gives you specific legal rights, which may vary based on location. It does not affect your statutory rights.
